For Sale BIOTEK BIOTEK Lionheart FX Microscope

For Sale Agilent BioTek Lionheart FX Automated Inverted Microscope with CO₂ Control

• Fully Functional
• Serviced & in Stock
• Current Model
• Made in 2020
• Good cosmetic condition
• Technical sales consultation available
• WARRANTY

________________________________________
Here is what you will receive:
• Agilent BioTek Lionheart FX Automated Inverted Microscope
• BioTek Lionheart Joystick
• BioTek CO2 Gas Controller
• BioTek Flow Regulator p/n: 1213032
• BioTek 2 Place Slide Holder p/n: 1220584
• BioTek Objective Calibration Plate p/n: 1222531
• BioTek Humidity Environmental Chamber p/n: 1450006
Objectives:
• BioTek 4x p/n:1220519
• BioTek 10x p/n:1220518
• BioTek 20x p/n:1220517
Filter/LED Modules:
• Laser Autofocus p/n: 1225010
• DAPI 377/447 p/n: 1225100, 365 LED p/n: 1225007
• GFP 469/525 p/n: 1225101, 46 LED p/n: 1225001
• Texas Red 586/647 p/n: 1225102, 590 LED p/n: 1225002
PH Filters:
• Brightfield p/n:1320523
• 4x p/n:1320520
• 10x/20x p/n:1320521
• 40x p/n:1322026

Lionheart FX Automated Inverted Microscope Configuration:
Imaging Modes: Fluorescence, brightfield, phase contrast, color brightfield
Incubation:
• Temperature control ranges from 8 DegC over ambient to 40 DegC
• Temperature variation ± 0.5 DegC across the plate @ 37 DegC
• Top and bottom incubation controlled via software-adjustable gradient.
Environment Control:
• CO2 Control: 0-20% CO2 control with gas controller
• Humidity Control: humidity chamber with rapid gas recharge
Microplates/Labware:
• Standard 6-, 12-, 24-, 48-, 96-, and 384-well microplates with 128 x 86 mm geometry microplate slides
• T25 and T75 cell culture flasks (with adapter/stage insert), and 35 mm, 60 mm, and 100 mm Petri dishes (with adapter).
• Maximum Plate Height: 43.4 mm without dispense tips and using the standard stage insert (1.5").
Read Speed:
• At 20x using standard Autofocus: < 12 minutes
• At 20x using Laser Autofocus: < 7 minutes
Camera Features:
• Interface: USB3
• Sensor Type: Monochrome CCD Sony ICX
• Resolution: 1280 x 960 pixels
• Image Format: 16-Bit TIFF

Customization/Options: N/A

Testing performed by our in-house service team:
The Lionheart FX Automated Inverted Microscope passed all tests and was found to be fully functional:
• We verified power and system initialization.
• We confirmed connectivity with the software.
• We checked the CO2 module power and mixing fan operation.
• We verified all objective positions.
• We inspected all filter positions.
• We assessed all phase contrast (PH) filter positions.
• We performed objective calibrations.
• We evaluated fluorescence modes using a sample slide.
• We confirmed performance across all objective magnifications.
• We tested incubation up to 40°C.
• We verified XY stage positioning accuracy.
• We assessed both manual and autofocus functions.
• We confirmed proper joystick operation.

Instrument Overview:
• Lionheart FX Automated Inverted Microscope provides automated imaging with integrated environmental control.
• Equipped with a CO₂ module and a humidity chamber for controlled imaging conditions.
• Motorized XY stage enables precise positioning and repeatable imaging.
• Includes fluorescence modules (DAPI, GFP, Texas Red) for multi-channel imaging.
• Supports multiple objectives for flexible magnification and imaging needs.
• Integrated autofocus and joystick control for accurate and efficient operation.

Instrument Application:
• Live cell imaging
• Fluorescence microscopy
• Cell culture monitoring
• Time-lapse imaging
• Brightfield and phase contrast imaging

The Key Features:
• Integrated CO₂ control module
• Motorized XY stage
• Autofocus system
• Fluorescence imaging capability
• Multiple objective lenses
• Joystick control
